BASIC OPERATION
35
(b)Step Setting:
Press the left and right
arrow keys ( , ) to
fine tune the voltage
setting at the digit
level. The selected digit
will have a yellow dot
directly underneath.
Press the up and down
arrow keys (
, )
to adjust the selected
digit. Press the Voltage
key again to finish and
exit setting the voltage.

Current Press the Current key
and the current setting
on the LCD is
activated. A yellow dot
appears under the
current digit.
I-Set
2.000 A
(a)Use the number pad (keys: 0~9,
Clear) to set the current value and
then press the Enter key.
To enter 1.2345A:
          

The input dialog box appears on
the LCD:
1.2345
