SAVE/RECALL
61
Method 2:
Press the Menu key
Use the up/down arrow keys to select
Recall Setup.
Press Enter to enter the Recall Setup
interface.

Use the left and right arrow keys to
select which setting to recall.
Press the Enter key to confirm the
selection.

Power On
Settings In the main menu, the interface parameter settings
area shows
PowOnSetup settings. There are 11
PowOnSetup settings to choose from, Rst,
SAV0~SAV4 and SAV5~SAV9.
The main difference between SAV0~SAV4 and
SAV5~SAV9 is that SAV0~SAV4 are user saved
settings and don’t contain the Power On/Off state
(
Output State is always off) while the SAV5~SAV9
contain the Power On/Off state. The SAV5~SAV9
settings are synced from corresponding
SAV0~SAV4 settings and are identical but for the
the Power On/Off state. The Power On/Off states
simply indicate if the
Output State can be on or off.
The relationship between SAV0~SAV4 and
SAV5~SAV9 is as follows:
SAV0 SAV5
SAV1 SAV6
