PPH-1503 User Manual
74
Auto IP Follow steps A~F in the previous section,
Manu IP, above.
G. Press the Enter key and select Auto IP.
The device will automatically obtain an IP
address and subnet address mask based
on the current network configuration.The
unit will set the IP address in the range of
169.254.0.1 to 169.254.255.254 with a
subnet of 255.255.0.0. The parameters will
be displayed in the parameter area. Use
the arrow keys to view the parameters.

H. Press the Menu key to exit and return
to the main menu.
PC Operation 1. Enter the IP address into Microsoft Internet
Explorer (IE). After entering the IP address you
will be shown the Welcome screen which displays
the instrument information. The page also
provides three links: Welcome Page, Browser Web
Control and View & Modify Configuration
(network settings).
