GW Instek PPH-1503 User Manual
Page 16
PPH-1503 User Manual
16
Linear Output
Circuit (Linear
Regulator)
The Q306, Q307 dividers reduce the heat on a
single component. The U303, U301, U403, U401
and U402 components form a control circuit to
achieve accurate output.
Auxillary Power
Supply
The independent auxillary DC power supply is
achieved with the U101, T101 and Q102~Q105
components.
