PPH-1503 User Manual
48
Panel Operation Output Press the Ouput key.
When the Output key is
lit, pulse current
measurement is active.
When no pulse current is
detected, NO PULSE will
be dispalyed in red on the
LCD screen. The unit will
wait until the next pulse is
detected.
The measurement
settings can be
edited during
measurement. The
H, L, A keys on the
keypad can be
used to perform
fast-switching
between
measurement
modes.



H IGH



L OW



A VER
Note
The LCD display
will indicate which
measurement
mode is active with
an orange line
under the active
mode for HIGH,
LOW or AVER.



H IGH
NO PULSE
