GETTING STARTED
29
Screw the terminals in a
clockwise direction to tighten.
Note
For safety considerations, please keep in mind that the
front panel and rear panel terminals are physically
connected.
Wire Gauge Load wires must have enough current capacityto
minimize cable loss and load line impedance.
Voltage drop across a wire should not excess 0.5V.
The following list is the wire current rating at
450A/cm2.
Wire Size(AWG) Maximum Current (A)
20 2.5
18 4
16 6
14 10
12 16
Turning the Output On/Off
Panel Operation Press the Output key to
turn the output on. The
Output key will light-up
when the output is on.
The status display on the
LCD display will also turn
on.
OFF ON
