PPH-1503 User Manual
20
Current
Setting key Press the Current key to set the
current settings. See page 35 for
operation details.
Front and
Rear output
toggle key

Front and rear output toggle
switch. The key will be lit when
the output is set to the rear
outputs.
Rear panel output:
 
Output key The Output key turns the output
on or off. The Output key will
lightup when the output is on.
On:
LOCK key

The Lock key is used to disable all
the panel keys except for the
Output key. Pressing the Lock key
for at least 2 seconds will turn the
panel lock on or off. The Lock key
can also be used to exit from
remote control mode. When the
panel lock is active the Lock key
will light up.
Locked：
 
