PPH-1503 User Manual
134
Specifications
The specifications apply under the following conditions: The PPH-1503
is powered on for at least 30 minutes, within +18°C~+28°C.
DC GENERAL MEASUREMENT TIME CHOICES 0.01 ~ 10PLC 1 ,0.01PLC/step
AVERAGE READINGS 1~10
TYPICAL READING TIME 2,3 31ms
DC VOLTAGE
OUTPUT
(23℃±5℃) OUTPUT VOLTAGE 0~15V
OUTPUT ACCURACY ± (0.05%+10mV)
PROGRAMMING RESOLUTION 2.5mV
READBACK ACCURACY 3 ± (0.05%+3mV)
READBACK RESOLUTION 1mV
OUTPUT VOLTAGE RISING TIME 0.15ms (10% ~ 90%)
OUTPUT VOLTAGE FALLING TIME 0.65ms (90% ~ 10%)
LOAD REGULATION 0.01%+2mV
LINE REGULATION 0.5mV
STABILITY 4 0.01%+0.5mV
RECOVERY TIME(1000%LOAD
CHANGE) <40us (<100mV)
<80us (<20mV)
RIPPLE AND NOISE 5 1mV rms(0~1MHz)
8mVpp(20Hz~ 20MHz)
DC CURRENT
(23℃±5℃) OUTPUT CURRENT 0 ~ 5A (0 ~ 9V)
0 ~ 3A (9 ~ 15V)
SOURCE COMPLIANCE ACCURACY ±(0.16%+5mA)
PROGRAMMED SOURCE
RESOLUTION
1.25mA
READBACK ACCURACY 3 5A range: ±(0.2%+400uA)
5mA range: ±(0.2%+1uA)
READBACK RESOLUTION 5A range: 100uA
5mA range: 0.1uA
CURRENT SINK CAPACITY 0 ~ 5V: 2A
5 ~ 15V:(2A derate 0.1A)/V
LOAD REGULATION 0.01%+1mA
LINE REGULATION 0.5mA
STABILITY 4 0.01%+50uA
DVM INPUT VOLTAGE RANGE 0 ~ 20VDC
INPUT IMPEDANCE 10 11 Ω
MAXIMUM INPUT VOLTAGE -3V, +22V
READING ACCURACY 3 ± (0.05%+3mV)
READING RESOLUTION 1mV
PULSE CURRENT
MEASUREMENT TRIGGER LEVEL 5mA ~ 5A, 5mA/step
HIGH TIME/LOW TIME/AVERAGE
TIME 33.3us to 833ms, 33.3us/step
TRIGGER DELAY 0 ~ 100ms,10us/steps
AVERAGE READINGS 1 ~ 100
