PPH-1503 User Manual
52
Parameter
Settings
IntTime
Use the arrow keys to select
IntTime
then
press Enter. Use the arrow keys to select a
time setting.
If
SetTime
was selected, press Enter and
then enter the long current integration
time. Press Enter to save the setting and
return to the long integration
measurement menu.
If
AutoTime
was selected, press Enter to
confirm and to go back to the long
integration measurement menu.
For manually set integration times, if the
set time is not an integer multiple of the
integration cycle time, the system will
automatically round down to closest
maximum integer multiple that can be
set.The time range is 850mS to 60S (50Hz)
and 840mS to 60S (60Hz). The default unit
is seconds (S).
TrigEdge
Use the arrow keys to select
TrigEdge
and
then press Enter. Use the arrow keys to
select the type of trigger and press Enter to
confirm the trigger settings and to return
to the long integration measurement
menu.
Timeout
Use the arrow keys to select
Timeout
and
then press Enter. Enter the timeout settings
and press Enter again to confirm and to
return back to the long integration
measurement menu. The time range is
1~63S. The default unit is seconds (S).
