REMOTE CONTROL
123
Event Registers
The operation, measurement and questionable status register groups all
have event registers. The event registers are read only registers that
reflect the status of the unit. Individual bits in the event registers are
latched (set) when a corresponding event occurs and will remain latched
even if the corresponding event changes, as long as the event bit is still
set. The register query (*ESR) or the command (*CLS) will automatically
clear any set bits in the event registers. The reset command (*RST) will
not clear the bits in the event register. Queries for the event registers will
return a binary-weighted decimal value that represents the state of all
the bits in an event register.
Enable Registers
The enable registers define which bits in the corresponding event
register can be latched (set). The enable register can be read and written
to. Any queries for the enable register will not clear the value in the
register. The *CLS command will not clear the enable register, but will
clear the events in the event register. To allow the individual bits in the
event registers to be set, the corresponding bits in the enable registers
must be set, where each bit is represented by a binary number.
Status Byte Register
The status byte register reports the status of the other status registers.
The message available bit (bit 4), will indicate when there is a message in
the output buffer. Clearing an event register will clear the corresponding
bit in the status byte condition register. Reading all the data in the
output buffer will clear the message available bit. To set the enable
register mask for the status byte register and to generate an SRQ (service
request) you must use the *SRE command to write the appropriate
decimal value to the register.
Bit Definition for the Status Byte Register
Bit number Decimal
value Definition
