BASIC OPERATION
41
REAR/
FRONT When the output is set for
the rear panel terminals,
REAR is displayed in
yellow.
When the output is set for
the front panel, FRONT is
displayed in yellow.
REAR
FRONT
ON/OFF
When the output is off, OFF
in displayed.
When the output is on, ON
is displayed.
OFF
ON
DVM
Description The PPH-1503 has a separate digital voltmeter
with a measurement range of 0~+20VDC. When
using the voltage meter, the power supply must be
properly grounded.
Parameter
Description Intrate Sets the reading rate of DVM
measurements based on the number
of PLCs.
0.01PLC~10.00PLC.
1PLC=16.7ms(60Hz)/20ms(50Hz).
*PLC stands for Power Line Cycle
