PPH-1503 User Manual

18

Setting
Display

Displays the voltage and current settings.

V-Set

15.000 V

I-Set

5.0000 A

Parameter
Settings
Display

Displays the parameter settings. For details on setting
parameters, see page 20. The following figure shows the
F1 parameter settings (

V AND I

), for example.

Status
Display

Display the current status of the instrument.

Status

Output mode

CV mode:

C V

CC mode:

C C

Overvoltage protection

Enabled:

O.V.P

Disabled:

O.V.P

Alarm

Enabled:

BEEP

Disabled:

BEEP

Key lock

Locked:

LOCK

Unlocked:

LOCK

CurrRange:

5 A

LimMode:

Limit

PowOnSetup:

RST

OutputRelay:

One

O.V.P:

Off

RecallSetup:

---

IntRate:

1.00 PLC

AverRead[1][2]:

1
