OVERVIEW
17
Front Panel
   



  



  
  



  



  
 

PPH-1503
LCD display
Numberpad and
secondary function keys
Arrow keys
DVM inputs
Front panel output
terminals
Function keys
Power button
Display
Voltmeter
Indicators Displays the output voltage with up to 5 digits of
resolution. The default units are Volts (V).
15.000
v
Ammeter
Indicator Displays the output current with up to 5 digits of
resolution, depending on the current range (5A/5mA).
The current range is selectable between A and mA.
5.0000
A
or
5.0000
mA
