OVERVIEW
19
Remote connectivity
Local mode: RMT Remote: GPIB
LAN
USB
Output Switching the Output Source
Front: FRONT Rear: REAR
Output State
On: ON Off: OFF
Function
Display Displays the unit functions. There four functions:
F1: Basic power supply function (V AND I);
F2: Digital Voltmeter function (DVM);
F3: Pulse current meter function (PULSE);
F4: Long integration current measurement function
The basic power supply function is shown below. (The
active function is shown in yellow.)
Function
Keys
Menu key Menu key to enter or exit from
system settings.
Voltage
Setting key Press the Voltage key to set the
voltage settings. See page 34 for
operation details.
