PPH-1503 User Manual
38
Note:
1. The Clear key can be used to clear numbers that
have already been entered.
2. Voltage and current parameter values use stepped
input values. All other numerical parameters can use
the number pad to enter parameter values.
Operation REAR /
FRONT After setting all the parameters the
Rear key can be used to set the
output to the front or rear output
terminals.
Pressing the Rear key will toggle the
output between the front and rear
terminals.
When set to rear, the Rear key will
light up and REAR will appear in the
status bar on on the LCD.
When set to front, the Rear key will
not be lit and FRONT will appear in
the status bar on the LCD.

REAR

FRONT
