GW Instek PSW-Series User Manual - Manual (Page 93)

OPERATION
93
Note
*Setting F-92 to 0 or 1 will disable loading a test
script at startup. 0 will turn the output off at
startup. 1 will turn the output on at startup. See
the power on configuration settings for details,
page 110.
Note
When a script starts to run, there is no way to abort
the script. Pressing the Output key has no effect. If
you wish to stop a test early, turn the power off.
Export Test Script to USB
Overview The Export Test function saves a test file to the
root directory of a USB flash drive.
 Files will be saved as tXXX.tst where XXX is
the memory number 001~010 from which
the test script was exported from.
 Files of the same name on the USB flash
drive will be written over.
Steps 1. Insert a USB flash drive into the
front panel USB-A slot.
2. Turn on the power. MS (Mass Storage) will be
displayed on the screen after a few seconds if
the USB drive is recognized.
