PSW Series User Manual

110

Power On Configuration Settings

CV Control

Sets the constant voltage (CV) control mode
between local and external voltage/resistance
control. For external voltage control, see page
119 (External Voltage Control of Voltage
Output) and
page 124 (External Resistance
Control of Voltage Output)
.

F-90

0= Panel control (local)
1 = External voltage control
2 = External resistance control
(Ext-R 10kΩ = Vo,max)
3 = External resistance control
(Ext-R

10kΩ = 0)

CC Control

Sets the constant current (CC) control mode
between local and external voltage/resistance
control. For details on external voltage control,
see page 122 (External Voltage Control of
Current Output) and
126 (External Resistance
Control of Current Output).

F-91

0= Panel control (local)
1 = External voltage control
2 = External resistance control
(Ext-R 10kΩ = Io,max)
3 = External resistance control
(Ext-R

10kΩ = 0)

Power-ON
Output

Configures the power supply to do one of the
following at startup: keep the output off, turn
the output on, or load a test script.

F-92

0 = OFF at startup
1 = ON at startup
T001 ~ T010 = Run test script
TXX at start up
