APPENDIX
163
Ripple and noise
r.m.s (*5) mA 72 27 15 10 5
Temperature coefficient ppm
/ºC 200ppm/°C of rated output current, after a
30 minute warm-up.
Protection Function
Over voltage protection
(OVP)
Setting range V 3-33 8-88 16-176 20-275 20-880
Setting accuracy ± (2% of rated output voltage)
Over current protection
(OCP)
Setting range
A
3.6-
39.6 1.35-
14.85 0.72-
7.92 0.45-
4.95 0.144-
1.584
Setting accuracy ± (2% of rated output current)
Over temperature protection
(OTP)
Operation Turn the output off.
Low AC input protection
(AC-FAIL)
Operation Turn the output off.
Power limit (POWER LIMIT)
Operation Over power limit.
Value (fixed) Approx. 105% of rated output power
Analog Programming and Monitoring
External voltage control
output voltage
Accuracy and linearity: ±0.5% of rated
output voltage.
External voltage control
output current Accuracy and linearity: ±1% of rated output
current.
External resistor control
output voltage Accuracy and linearity: ±1.5% of rated
output voltage.
External resistor control
output current Accuracy and linearity: ±1.5% of rated
output current.
Output voltage monitor
Accuracy % ±1 ±1 ±1 ±2 ±2
Output current monitor
Accuracy % ±1 ±1 ±1 ±2 ±2
Shutdown control Turns the output off with a LOW (0V to
0.5V) or short-circuit.
Output on/off control Possible logic selections:
Turn the output on using a LOW (0V to
0.5V) or short-circuit, turn the output off
using a HIGH (4.5V to 5V) or open-circuit.
Turn the output on using a HIGH (4.5V to
5V) or open-circuit, turn the output off
using a LOW (0V to 0.5V) or short-circuit.
