ANALOG CONTROL

137

CC MODE:
Output turned on

The diagram below shows the timing diagram
when the output is turned on when the PSW is
set to CC mode.

CV status

H

L

CC status

H

L

Output status

H

L

CC MODE:
Output turned off

The diagram below shows the output status
lines when the output is turned off in CC mode.

CV status

H

L

CC status

H

L

Output status

H

L
