CONFIGURATION
101
CV Control
F-90
0 = Panel control (local)
1 = External voltage control
2 = External resistance control
(Ext-R 10kΩ = Vo, max)
3 = External resistance control
(Ext-R 10kΩ = 0)
CC Control F-91
0 = Panel control (local)
1 = External voltage control
2 = External resistance control
(Ext-R 10kΩ = Io,max)
3 = External resistance control
(Ext-R 10kΩ = 0)
Power-ON Output F-92
0 = OFF at startup
1 = ON at startup
T001 ~ T010 = Run test script TXX at
start up
Master/Slave F-93
0 = Master/Local
1 = Master/Parallel1
2 = Master/Parallel2
3 = Slave/Parallel
4 = Slave/Series (Only 30V, 80V, 160V
models)
External Out Logic F-94 0 = High ON, 1 = Low ON
Power Switch trip F-95 0 = Enable , 1 = Disable
Calibration Settings*
Calibration
F-00 0000 ~ 9999
*Note
Power On and Calibration settings can only be set
during power up.
