A-2
IM 11B03G03-03E
Menu Name Command Name Function
Connect Connect Establishes a communication link with the analyzer.
Disconnect Drops a communication link with the analyzer.
User Level Sets a user level (A, B or C).
Com. Port Used to select a serial port for the communication with the
analyzer.
Com. Speed Used to select a communication speed to the analyzer.
Exit Exits the Maintenance Terminal.
File Upload to PC Uploads and saves parameter settings from the analyzer to
thedisk of the Maintenance Terminal.
Download to GC Downloads and saves parameter settings from the disk of
theMaintenance Terminal to the analyzer.
Display Alarm Status Opens the Alarm Status window.
Alarm History Opens the Alarm History window.
Alarm Details Opens the Alarm Details window.
Chromatogram Opens the Chromatogram window.
Analysis Results Opens an Analysis Results window.
GC State Process Commands to change to the Process mode.
Manual Commands to change to the Manual mode.
Lab Commands to change to the Lab mode.
Operation
Mode
Run Commands to change to the Run mode.
Pause Commands to change to the Pause mode.
Stop Commands to the Stop mode.
Command Cancel Cancels the operation mode reserved.
Measurement
State
Stream Sequence Commands to change to Stream Sequence.
Stream Select (Continuous) Commands to change to Stream (Continuous).
Stream Select (One Cycle) Commands to change to Stream (One cycle).
Calibration/Validation Commands to change to Calibration/Validation.
Calibration/Validation Start Commands to start the calibration/validation.
Calibration/Validation Stop Commands to stop the calibration/validation.
Selection Cancel Cancels the measurement scheduled.
Calibration/Validation Method Changes the calibration/validation method.
Manual/Range Manual Turns on or off valves and detectors in the Manual mode.
Range Select Changes the range.
Set Up Valve Change the timing for turning on/off the valve.
Peak Changes the peak information (peak name, gate time, etc.).
Help Contents Shows the Help contents of the GCMT.
Help Topics Shows a Help topic appropriate for a typed-in keyword.
About GCMT Displays version information on the GCMT.
4th Edition : Mar. 21, 2012-00
