<1. Overview of Maintenance Terminal>
1-5
IM 11B03G03-03E
n
How to Select Menus
l
Menus
The menu bar and control menu box contain menu items necessary in working with the
Maintenance Terminal. A menu is a list of classified functions (commands). From a menu, you
select a command to be executed.
• [Connect] Menu
F0104.ai
• Control Menu
F0105.ai
l
Dialog Box and Buttons
When you select a command from a menu, a dialog box pops up to ask you to specify details
about the command. Give the details and then select the appropriate button to execute the
command.
Dialog Box to Confirm Termination
F0106.ai
Button
l
Procedure
Example: To execute the [Disconnect] command in the Analyzer Operation window:
(1) Click on [Connect] on the menu bar.
The [Connect] menu opens.
F0107.ai
Click here.
• In a menu, selectable commands appear dark.
• The command can also be selected by typing the underlined letter with the [Alt] key held
down.
(2) Click on the [Disconnect] command.
A confirmation dialog box pops up.
(3) Click on the [OK] button.
The Disconnect command is executed.
