<6. Analysis Results Windows>
6-1
IM 11B03G03-03E
6. Analysis Results Windows
Analysis Results windows display the data analyzed by the analyzer. They consist of a to-
tal of eight windows: four acquisition windows that acquire analysis results and four ref-
erence windows that are used to open and refer to files. Also, on a history record window,
a graph window can be viewed at the same time. This chapter describes how to open and
close the Analysis Results windows, the types and configurations of the windows, how
to switch between the windows, how to save and read data, how to process and re-save
data, and how to graph and reset historical data.
Window Hierarchy
Analysis results
window *1
Analyzer Operation
window
Latest Analysis
Results window
Analyzer Operation
window
Confirmation message
Concentration Analysis
History window
Retention Time History
window
Lab Analysis Results
window
Filed Analysis
Results window
History windows with
graphic window
Filed Concentration
Analysis History window
Filed Retention Time
History window
Filed Lab Analysis
Results window
Double-click on the analysis
results icon.
Analysis results window *2
File reference
windows
Analysis results
windows
End of the analysis
results window
Minimize
[Exit] command
on the [File] menu
[Cancel]
[OK]
History windows
[Draw] command
on the [Graph] menu *3
*1: Appears as an icon.
*2: Switch to each window using the [Window] menu.
*3: The [Graph] menu can be used in a history window.
F0601.ai
4th Edition : Mar. 21, 2012-00
