<4. Chromatogram Window>

4-1

IM 11B03G03-03E

4. Chromatogram Window

The Chromatogram window displays chromatograms from the analyzer in detail. In addi-

tion to the most recent chromatogram, previous chromatograms saved in a file can also

be retrieved onto the display. This chapter describes how to open and close the Chroma-

togram window, how the window is composed, how to change the scale and zoom in the

window, and how to save and retrieve chromatograms.

Window Switching Sequence

Chromatogram

window

Analyzer

Operation

window

Click on the

[Chromatogram]

[Exit] command

F0401.ai

4.1

Opening and Closing the Chromatogram

Window

This section describes how to open and close the Chromatogram window.

Opening the Window

The Chromatogram window can be opened from the Analyzer Operation window in two ways: by

using the command in the menu or by double-clicking anywhere in the Chromatogram Display

area.

NOTE

Only one Chromatogram window can be opened at a time.

Procedure

(1) Click on the [Chromatogram] command in the [Display] menu in the Analyzer Operation

window or double-click anywhere in the Chromatogram Display area. The Chromatogram

window opens.
