n
Alarm Windows
Message
Description
Corrective Measures
History
deletion
Alarm history cannot be
cleared in User level A.
Invalid attempt to reset the alarm
history at the wrong user level.
Alarm histories can be reset at
user level B or C only.
Creation of
user alarm
description
Factory alarm
descriptions cannot be
changed. Select User
defined alarm.
A number other than the user
defined alarm numbers has been
specified when creating a user
alarm description.
Confirm the valid alarm numbers,
and then select a correct alarm
number.
n
Analysis Result Window
Message
Description
Corrective Measures
Memory
Memory AI location Error.
Not enough memory.
The memory is too low.
Check that memory is reserved
sufficiently for work.
File
operation
File name is incorrect.
This file is not XXX.
Invalid attempt to open the file
that does not contain the data
corresponding to the onscreen
window.
Open the file appropriate for the
on-screen window.
Read error. Data is
incorrect. Error occurred
reading a file.
Failed to open the file because it
contained invalid data.
Open the file that contains the
valid data.
Error occurred while
saving file. File cannot be
saved.
An error occurred while saving
file. Filed to save the file.
Eliminate the cause of the error
and then retry saving the file.
Data has been changed.
Do you want to save it?
Changes have been made to the
data of the window.
If the file needs to be saved
before the window is closed,
select “Yes.”
Data
editing
Entered valve is incorrect.
Only a numerical value
can be entered here.
Invalid attempt to type in a data
value other than numerals.
Type in a numeric data value.
Automatic
saving
Entered value is incorrect.
Automatic saving cycle
must be between 1 and
250.
An invalid number has been
typed in as the interval for
automatic saving.
For the interval for automatic
saving, type a whole number
from 1 to 250.
Graph
creation
Graph cannot be drawn.
No data available.
Cannot create a graph because
the currently open window does
not contain graph data.
Create a graph when data are
available.
Graph cannot be drawn.
Data is incorrect.
Cannot create a graph because
the selected range for the graph
being created contains invalid
data. This message also appears
if the selected range for the
graph does not contain any data.
Once again check the data for
the selected range of graph. Also
check that the range contains
necessary data.
Selection error.
Necessary data is not
selected.
Some of the data necessary
to create the graph remain
unselected.
Once again check that none
of the necessary data remain
unselected.
Selection error. You can
select 1 to 6 Peak names.
Seven or more peaks have been
selected at one time during peak
selection.
A graph can contain no more
than six peaks at a time. Select
no more than six peaks.
Selection error. Start time
is set after End time.
The starting time has been set at
an later time than the ending time
during time-axis setting (manual).
Set the starting time at a time
earlier than the ending time.
Graph cannot be drawn.
Min./max. axis scale of a
Logarithm graph cannot
be set or under zero.
The upper or lower limit of
the scale has been set at a
value smaller than zero during
the setting (manual) of the
logarithmic axis.
A logarithmic axis cannot indicate
values smaller than zero.
When setting the upper and
lower limits of a logarithmic axis,
use values larger than zero.
