Lexternal dimensions (k9404la), Lexternal dimensions (k9404ld) – Yokogawa GC1000 Mark II Process Gas Chromatograph User Manual
Page 17
10
IM 11B03G03-03E
4th Edition : Mar. 21, 2012-00
l
External Dimensions (K9404LA)
Weight: approximately 2 kg
Unit: mm
203
126
35
F11.ai
RS-422, D/I 12 V
Power supply
RS-232C
D-SUB 25P Socket
l
External Dimensions (K9404LD)
203
218
233
Unit: mm
126
11
0
96
7
5
40
Weight: approximately 2 kg
RS-422, D/I 12 V
Power supply
4-ø4.5
Mounting holes
RS-232C
D-SUB 25P Socket
K9404LD.ai
1.6
