<1. Overview of Maintenance Terminal>
1-4
IM 11B03G03-03E
1.3 Notes Before Use
The Maintenance Terminal is a software package which runs under Windows™. In this section,
you will learn basic operations common to the Windows™ software.
n Mouse
A mouse is used to work with the Maintenance Terminal.
l Basic Mouse Operations
The mouse cursor ( ) in the window moves as you move the mouse. Place the mouse cursor on
an item you want to select in a window and click the left mouse button to select it.
l Buttons
There are three ways to press mouse buttons:
Click: Press the left button and immediately remove your finger. Normally, most
clicking operations use the left button, but some may use the right button.
“Click” in this manual means to press the left button.
Double click: Press the left button twice in quick succession.
Drag:
Move the mouse from a starting position to an ending position while pressing
down the left button, and then release your finger. This is used, for example, to
select a number of items at once.
n Window Layout
The figure below illustrates the window layout, using the Analyzer Operation window as an
example.
F0103.ai
Border line
Menu bar
Close button
Minimize button Title bar Control menu box
