A-1
IM 11B03G03-03E
Appendix A Menus
This appendix summarizes the functions used in the Maintenance Terminal.
n LCD Emulator Window
Connect
Connect
Disconnect
Com. Port
Com. Speed
Disp. Reset
Exit Alt+F4
Help
How to Operat
About Topics
About LCD Emulator
9600bps
19200bps
38400bps
COM1
COM2
COM3
COM4
F01.ai
Menu Name Command Name Function
Connect Connect Establishes a communication link with the analyzer.
Disconnect Drops the communication link with the analyzer.
Com. Port Used to select a serial port for the communication with
the analyzer.
Com. Speed Used to select a communication speed to the analyzer.
Disp. Reset Turns off the LCD display and again opens the Analyzer
Status window.
Exit Exits the LCD emulator.
Help How to Operate Shows the operation procedures for the LCD emulator.
Help Topics Shows a Help topic appropriate for a typed-in keyword.
About LCD Emulator Displays the version information on the LCD Emulator
window.
n Analyzer Operation Window
Connect
Connect
Disconnect
User Level
Com. Port
Com. Speed
Exit Alt+F4
File
Upload to PC
Download to GC
Display
Alarm Status
Alarm History
Alarm Details
Chromatogram
Analysis Results
Manual/Range
Manual
Range Select
Set Up
Valve
Peak
Help
Contents
Help Topics
About GCMT
User Level A
User Level B
User Level C
Measurement State
Stream Sequence
Stream Select (Continuous)
Stream Select (One Cycle)
Calibration/Validation
Calibration/Validation Start
Calibration/Validation Stop
Selection Cancel
Calibration/Validation Method
GC State
Process
Manual
Lab
Operation Mode
Run
Pause
Stop
Command Cancel
Stream VLV
VLV1
VLV2
VLV3
VLV4
VLV5
VLV6
VLV7
VLV8
DET1
DET2
Heater
F02.ai
Name
Gate Std/On/Off Time
Result Unit/Measuring Range
Ref Task Number/Ref Peak Number
Gate Cut Method/Integ Method
Std Conc/Std Area/Calib Factor
4th Edition : Mar. 21, 2012-00
