Watlow EZ-ZONE ® PM Limit Controller • 6 • Chapter 1 Overview
EZ-ZONE ® PM Enhanced Limit PM4/6/8/9 Models - System Diagram
(with communications options 2, 3, 5 or 6)
Universal Sensor Input, Configuration Communications,
Red/Green 7-Segment Display
Note:
Number of inputs and outputs and various combinations of the same will vary
depending upon part number; see ordering matrix for more detail.
Output Status
Indicators
5 6
1
3
2
4
Zone
Address
Indicators
Channel
Indicates Zone
Address & Channel*
Indicates I/O
Status
* Channel indicator available
on PM4/8/9 only
Supervisory
&
Power
Board
Slot C
Limit
Controller
Board
Slot A
Output 2
Form A mechanical (5 A) relay
Output 1
None, Switched dc/open collector,
Form C mechanical (5 A) relay
Off, Limit,
Alarm
EZ-ZONE PM Enhanced Limit Controller System Diagram
with Communications
EZ Key/s
Programmable Functions
Digital Output (or Input) 5 & 6
(optional) None, Switched dc
Off,
Alarm
Network
Remote User Interface
Personal Computer
Programmable Logic Controller
Human Machine Interface
EIA 485 Communications
Standard Bus, Modbus RTU (optional)
Communi-
cations
Board
(optional)
Slot B
Analog Input 1
Off, Thermocouple, RTD (100Ω, 1kΩ),
Thermistor (5kΩ, 10kΩ, 20kΩ, 40kΩ),
Process (V, mV, mA, 1k potentiometer)
Digital Input (or Output) 5 & 6
(optional) none, switch, volts dc
None
Limit reset
Loop & alarms off
Silence alarm
Force Alarm
Lock keypad
Restore user settings
Input Sensor
Input
Functions
Output
Functions
Communications
EIA-232/485 Modbus RTU, Ethernet/IP,
DeviceNet, Modbus TCP, Profibus
Limit
