Watlow EZ-ZONE ® PM Limit Controller • 9 • Chapter 2 Install and Wire
2
RESET
101.5 mm
4.00 in
15.9 mm
0.63 in
53.3 mm
2.10 in
31.2 mm
1.23 in
30.9 mm
1.22 in
Side Front
Top
1/32 DIN
21.6 mm
(0.85 in)
Minimum
44.96 to 45.47 mm
(1.77 to 1.79 inches)
Recommended panel spacing
panel thickness 1.53 to 9.52 mm
(0.060 to 0.375)
21.6 mm
(0.85 in)
Minimum
22.2 to 22.5 mm
(0.87 to0.89 inches)
Chapter 2: Install and Wire
Dimensions
