Watlow EZ-ZONE PM User Manual

Page 59

Watlow EZ-ZONE

PM Limit Controller

•

Chapter 6 Setup Page

Setup Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus

Relative

Address

CIP

Class

Instance

Attribute

hex (dec)

Pro-

fibus

Index

Param-

eter ID

Data

Type

Read/

Write

[`A;Lo]
[ A.Lo]

Alarm (1 to 4)

Alarm Low Set Point

If Alarm Type (Setup

Page, Alarm Menu) is

set to:

process - set the pro-

cess value that will

trigger a low alarm.

-1,999.000 to 9,999.000°F or

units

-1,128.000 to 5,537.000°C

32.0°F

or units

0.0°C

Instance 1

Map 1 Map 2

1482

1882

Offset to next

instance (Map

1) equals +50

Offset to next

instance (Map

2) equals +60

0x6D

(109)

1 to 4

9002

float
RWES

[`A;hi]
[ A.hi]

Alarm (1 to 4)

Alarm High Set Point

If Alarm Type (Setup

Page, Alarm Menu) is

set to:

process - set the pro-

cess value that will

trigger a high alarm.

-1,999.000 to 9,999.000°F or

units

-1,128.000 to 5,537.000°C

300.0°F

or units

150.0°C

Instance 1

Map 1 Map 2

1480

1880

Offset to next

instance (Map

1) equals +50

Offset to next

instance (Map

2) equals +60

0x6D

(109)

1 to 4

9001

float
RWES

[`A;LA]
[ A.LA]

Alarm (1 to 4)

Alarm Latching

Turn alarm latching on

or off. A latched alarm

has to be turned off by

the user.

[nLAt]

Non-Latching (60)

[`LAt]

Latching (49)

Non-

Latching

Instance 1
Map 1 Map 2

1492

1892

Offset to next

instance (Map

1 equals +50,

for Map 2

equals +60)

0x6D (109)

1 to 4

9007

uint
RWES

[`A;bL]
[ A.bL]

Alarm (1 to 4)

Alarm Blocking

Select when an alarm

will be blocked. After

startup and/or after the

set point changes, the

alarm will be blocked

until the process

value enters the normal

range.

[`oFF]

Off (62)

[`Str]

Startup (88)

[StPt]

Set Point (85)

[both]

Both (13)

Off

Instance 1
Map 1 Map 2

1494

1894

Offset to next

instance (Map

1 equals +50,

for Map 2

equals +60)

0x6D (109)

1 to 4

9008

uint
RWES

[`A;Si]
[ A.Si]

Alarm (1 to 4)

Alarm Silencing

Turn alarm silencing on

to allow the user to dis-

able this alarm.

[`oFF]

Off (62)

[``on]

On (63)

Off

Instance 1
Map 1 Map 2

1490

1890

Offset to next

instance (Map

1 equals +50,

for Map 2

equals +60)

0x6D (109)

1 to 4

9006

uint
RWES

Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.

These parameters/prompts are available in this menu with firmware revisions 11.0 and

above.

R: Read

W: Write

EEPROM

User Set
