Watlow EZ-ZONE ® PM Limit Controller • 54 • Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[``Fi]
[ Fi] Output Process (3)
Output Function In-
stance
Set the instance of the
function selected above.
1 to 4 1 Instance 3
Map 1 Map 2
806 926
0x76 (118)
3
4
98 18004 uint
RWES
[`S;Lo]
[ S.Lo] Output Process (3)
Scale Low
Set the scale low for
process output in elec-
trical units. This value;
in volts or milliamps,
will correspond to range
low value.
-100.0 to 100.0 0.00 Instance 3
Map 1 Map 2
816 936
0x76 (118)
3
9
99 18009 float
RWES
[`S;hi]
[ S.hi] Output Process (3)
Scale High
Set the scale high for
process output in elec-
trical units. This value;
in volts or milliamps,
will correspond to range
high value.
-100.0 to 100.0 10.00 Instance 3
Map 1 Map 2
818 938
0x76 (118)
3
0xA (10)
100 18010 float
RWES
[`r;Lo]
[ r.Lo] Output Process (3)
Range Low
Set the minimum value
of the retransmit value
range in process units.
When the retransmit
source is at this value,
the retransmit output
will be at its Scale Low
value.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
0.0°F or
units
-18°C
Instance 3
Map 1 Map 2
820 940
0x76 (118)
3
0xB (11)
101 18011 float
RWES
[`r;hi]
[ r.hi] Output Process (3)
Range High
Set the maximum value
of the retransmit value
range in process units.
When the retransmit
source is at this value,
the retransmit output
will be at its Scale High
value.
100°F or units 38°C 100.0°F or
units
38.0°C
Instance 3
Map 1 Map 2
822 942
0x76 (118)
3
0xC (12)
102 18012 float
RWES
[`o;CA]
[ o.CA] Output Process (3)
Calibration Offset
Set an offset value for a
process output.
-1,999.000 to 9,999.000°F or
units
-1,110.555 to 5,555.000°C
0.0°F or
units
0.0°C
Instance 1
Map 1 Map 2
732 852
0x76 (118)
3
7
105 18007 float
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.
* These parameters/prompts are available in this menu with firmware revisions 11.0 and
above.
R: Read
W: Write
E: EEPROM
S: User Set
