Watlow EZ-ZONE
®
PM Limit Controller
•
68
•
Chapter 7 Factory Page
Factory Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative Ad-
dress
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[ULoC]
[FCty]
Unlock Menu
[Code]
[CodE]
Security Setting
Public Key
If Rolling Password
turned on, generates a
random number when
power is cycled. If Roll-
ing Password is off
fixed number will be
displayed. The key can
be used to gain access
when the password is
not known.
Customer Specific
0
- - - -
- - - -
- - - -
3020
uint
R
[pass]
[PASS]
Security Setting
Password
Enter the User or Ad-
ministrator password
to gain access. Exit this
menu and renter Facto-
ry Page, Security menu
after valid password is
supplied.
-1999 to 9999
0
- - - -
- - - -
- - - -
3022
int
RW
[diag]
[FCty]
Diagnostic Menu
[``Pn]
[ Pn]
Diagnostics
Part Number
Display this controller's
part number.
15 characters
- - - -
- - - -
0x65 (101)
1
9
115
1009
string
RWE
[`rEu]
[ rEu]
Diagnostics
Software Revision
Display this control-
ler's firmware revision
number.
1 to 10
- - - -
- - - -
0x65 (101)
1
0x11 (17)
116
1003
string
R
[S;bLd]
[S.bLd]
Diagnostics
Software Build Num-
ber
Display the firmware
build number.
0 to 2,147,483,647
- - - -
Instance 1
Map 1
Map 2
8
8
0x65 (101)
1
5
- - - -
1005
dint
R
[``Sn]
[ Sn]
Diagnostics
Serial Number
Display the serial num-
ber.
0 to 2,147,483,647
- - - -
- - - -
0x65 (101)
1
0x20 (32)
- - - -
1032
string
RWE
[dAtE]
[dAtE]
Diagnostics
Date of Manufacture
Display the date code
(YYWW). Where YY =
year and WW= week.
.
0 to 2,147,483,647
- - - -
Instance 1
Map 1
Map 2
14
14
0x65 (101)
1
8
- - - -
1008
dint
RWE
[iP;aC]
[iP.AC]
Diagnostics
IP Address Mode
Actual address mode
(DHCP or Fixed).
[dhCP]
DHCP (1281)
[F;Add]
Fixed Address
(1284)
DHCP
- - - -
- - - -
- - - -
17013
- - - -
Note:
Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces.
R: Read
W: Write
E:
EEPROM
S:
User
Set
