Watlow EZ-ZONE ® PM Limit Controller • 41 • Chapter 5 Operations Page
5
Chapter 5: Operations Page
Navigating the Operations Page
[``Ai]
[oPEr]
Analog Input Menu
[`Ain] Analog Input Value
[`i;Er] Input Error
[`i;Ca] Calibration Offset
[`dio]
[oPEr]
Digital Input/Output Menu
[```5]
[`dio]
Digital I/O (5 to 6)
[`do;S] Output State
[`di;S] Input State
[`ei;S] Event Status
[LiM]
[oPEr]
Limit Menu
[`LL;S] Limit Low Set Point
[`Lh;S] Limit High Set Point
[`lCr] Limit Clear Request *
[`l;st] Limit State *
[ALM]
[oPEr]
Alarm Menu
[```1]
[ALM]
Alarm (1 to 4)
[`A;Lo] Low Set Point
[`A;hi] High Set Point
[a;Clr] Clear Request *
[a;sir] Silence Request*
[`a;st] State *
To navigate to the Operations Page, follow the steps below:
1. From the Home Page, press both the Up ¿ and Down ¯ keys for three seconds. [``Ai] will appear in the up-
per display and [oPEr] will appear in the lower display.
2. Press the Up ¿ or Down ¯ key to view available menus.
3. Press the Advance Key
‰ to enter the menu of choice.
4. If a submenu exists (more than one instance), press the Up ¿ or Down ¯ key to select and then press the Ad-
vance Key ‰ to enter.
5. Press the Up ¿ or Down ¯ key to move through available menu prompts.
6. Press the Reset Key
RESET
to move backwards through the levels: parameter to submenu; submenu to menu; menu
to Home Page.
7. Press and hold the Reset Key
RESET
for two seconds to return to the Home Page.
On the following pages, top level menus are identified with a yellow background color.
Note:
Some of these menus and parameters may not appear, depending on the controller's options. See model
number information in the Appendix for more information. If there is only one instance of a menu, no sub-
menus will appear.
Note:
Some of the listed parameters may not be visible. Parameter visibility is dependent upon controller part
number.
