Watlow EZ-ZONE ® PM Limit Controller • 51 • Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[``Fn]
[ Fn] Digital Output (5 to 6)
Digital I/O Function
Select what function
will drive this output.
[`oFF] Off (62)
[ALM] Alarm (6)
Off Instance 5
Map 1 Map 2
1008 1128
Offset to next
instance (Map
1 & Map 2)
equals +30
0x6A (106)
5 to 6
5
83 6005 uint
RWES
[``Fi]
[ Fi] Digital Output (5 to 6)
Digital I/O Function
Instance
Set the instance of the
function selected above.
1 to 4 1 Instance 5
Map 1 Map 2
1010 1130
Offset to next
instance (Map
1 & Map 2)
equals +30
0x6A (106)
5 to 6
6
84 6006 uint
RWES
[`leu]
[ LEv] Digital Input (5 to 6)
Active Level
Select which action will
be interpreted as a true
state.
[high] High (37)
[LoW] Low (53)
High Instance5
Map 1 Map 2
1320 1560
Offset to next
instance (Map
1 & Map 2)
equals +20
0x6E (110)
5 to 6
1
137 10001 uint
RW
[``Fn]
[ Fn] Digital Input (5 to 6)
Action Function
Select the function that
will be triggered by a
true state.
[none] None (61)
[lmr] Limit Reset, edge trig-
gered (82)
[`F;AL] Force Alarm To Occur,
level triggered (218)
[`AoF] Control Loops Off and
Alarms to Non-alarm State,
level triggered (220)
[`SiL] Silence Alarms, edge
triggered (108)
[ALM] Alarm (6)
[p;loc] Keypad Lockout, level
triggered (217)
[USr;r] User Settings Re-
store, edge triggered (227)
None Instance 5
Map 1 Map 2
1324 1564
Offset to next
instance (Map
1 & Map 2)
equals +20
0x6E (110)
5 to 6
3
138 10003 uint
RWES
[``Fi]
[ Fi] Digital Input (5 to 6)
Function Instance
Select which instance of
the Event Function that
will be triggered by a
true state.
0 to 4 0 Instance 5
Map 1 Map 2
1326 1566
Offset to next
instance (Map
1) equals +20
0x6E (110)
5 to 6
4
139 10004 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be read
with other interfaces.
* These parameters/prompts are available in this menu with firmware revisions 11.0 and
above.
R: Read
W: Write
E: EEPROM
S: User Set
