Chapter Three Control Reference
Sets/Queries the vertical position of center of the grid on the zoomed trace Mx. The unit of
measurement is the screen height, that is, 0.375 means a shift of three of the eight divisions. A
positive value moves the trace downwards.
VerPos
From -1.5 to 1.5 step (8 digits)
Double
Range
Description
Sets/Queries the horizontal magnification of the trace Mx. The magnification will be in a 1 2 5 10
sequence unless variable horizontal magnification has been set.
HorZoom
From 0.1 to 1e+006 step (8 digits)
Double
Range
Description
Sets/Queries the horizontal position of center of the grid on the zoomed trace Mx. The unit of
measurement is the screen width, that is, 0.3 means a shift of three of the ten divisions. A positive
value moves the trace to the left.
HorPos
From -0.5 to 0.5 step (8 digits)
Double
Range
Description
PASSFAIL app.PassFail
Names of the forms app.PassFail("Qremote").xxxx and app.PassFail("Qx").xxxx are aliases of simpler names which are
described in this section of the manual. Examples of alias pairs are as follows -
app.PassFail.PassFail("Qremote").Operator is equivalent to app.PassFail.Qremote.Operator
app.PassFail.PassFail("Qx").Out.Result is equivalent to app.PassFail.Qx.Out.Result
Please see under app.Acquisition.Channels("Cx") for a programming example.
ActionOn Enum
Alarm Bool
EnableActions Bool
PredefinedConditions Enum
PrintScreen Bool
Save Bool
Stop Bool
StopAfter Integer
StopTesting Bool
SummaryView Bool
Testing Bool
3-88 916435 RevA
