-Gilderfluke & Co. Mp3-50/40 Audio/Show Controller ver. 1.15 copyright 2003 DCM-
Card at 00h/__0 | 4 Mbits (512KBytes) memory | i:Y p:N s:N
A/Green: Open
B/Red: Open
C/Blue: Open (disable RTC schedules)
D/White: Open (close sets clock to 03:05:01)
no shows loaded
a) play A sound
c) STMP Config
h) set time (schedule loaded- Y)
v) Verify
x) eXit
11:52:04 2 03/24/03 sc:dis Command-
(Sample data: Your show data will differ from what is shown.)
When you enter configuration the Mp3-50/8 or Mp3-50/40 will display
the following screen if shows are loaded:
-Gilderfluke & Co. Mp3-50/40 Audio/Show Controller ver. 1.15 copyright 2003 DCM-
Card at 00h/__0 | 4 Mbits (512KBytes) memory | i:Y p:N s:N
A/Green: Open
B/Red: Open
C/Blue: Closed (enable RTC schedules)
D/White: Open (close sets clock to 03:05:01)
show 01h/__1 looping @ frame 1E240h/_123456
FileName: LIFETES3.A00 | #shows: 11h/_17 | #channels: 01h/__1 | offset: 00h/__0
a) play A sound
c) STMP Config
h) set time (schedule loaded- Y)
i) show Info
e) stop at End
l) Loop show
p) Play show
s) Stop show
v) Verify
x) eXit
11:52:04 2 03/24/03 sc:123 Command-
(Sample data: Your show data will differ from what is shown.)
To redraw the screen at any time, just press the
The three flags ‘i’, ‘p’, and ‘s’ are used to help in diagnosing problems:
i)
Shows ‘Y’ if interface between the Show Control and Mp3 Player
sides of the Mp3-50/8 or Mp3-50/40 is active. If this is ‘N’, the
Mp3 player side of the unit is probably not running. Either it has
