Outputs. The last eight outputs (on channel ‘1’) will be used
for triggering the Mp3 Player.
3) Click ‘OK’ to create these channels.
4) Go to PC•MACs 'Channels Pulldown'/'Create Multiple Chan-
nels....'.
5) Select zero digital and one 8 bit analog channel. This will be
your audio level control channel at address ‘2’.
6) Click ‘OK’ to create this channel.
When you have finished programming your show you will
AutoDownload it to the Mp3-50/8. Set the ‘First Channel’ to ‘0’
and the ‘Last Channel’ to ‘2’ on the PC•MACs File Pulldown/Save
as AutoDownload.... window.
In the Mp3 Configurator Program:
1) Track Setup Tab: Point it at your SmartMedia card and set as
needed.
2) PlayLists Tab: Set up as needed, if needed.
3) Audio Tab: Set audio levels and EQ as needed. Enable Real-
Time Audio Level Control. You can control one or both out-
puts from the analog channel you have created. Set the
addresses of the Level Control Channels to ‘2’.
Enable/Disable amplifier as needed.
4) Input Tab: You will be using the MPU inputs in this case. Dis-
able ALL of the Optoisolated Inputs.
5) MPU Input Tab: Set up the inputs to select and start Au-
dioFiles and ramp audio levels, as needed.
6) Serial Control Tab: The Brick Address is usually set at '0', un-
less you will be accessing the card using Net Serial com-
mands. The Repeater Control Channel must be set to '1'.
First animation Channel Number must be set to '0'.
Disable/Enable Net Serial and IR Trigger modes as needed
(these are
usually disabled)
7) DMX-512 Control Tab: Enable DMX-512 Control, unless you
are using MIDI, Net Serial or IR Trigger Modes. Enable DMX-
512 checksums if you will be feeding DMX-512 from any
Gilderfluke & Company products (
usually enabled). The Re-
peater Control Channel and First Animation channel num-
ber were set on a previous tab.
