Mp3-50 Configurator: MPU Input Setup
(Mp3-50/8, and Mp3-50/40)
The Mp3-50/8 and Mp3-50/40 have eight ‘hidden’ outputs which can
be sent to the Mp3 Player to trigger and control it. These are in addition to
the eight optically isolated inputs the Mp3 Player has on its own. In most
cases, you will disable the Mp3 Players’ optically isolated inputs and use
these inputs instead to trigger and control the Mp3 Player from the Show
Control side of the Mp3-50/8 or Mp3-50/40.
You can set any of the eight inputs as unused, an independent control,
or part of a binary address:
