Disable/Enable Net Serial and IR Trigger modes as needed
(these are
usually disabled)
7) DMX-512 Control Tab: Enable DMX-512 Control, unless you
are using MIDI, Net Serial or IR Trigger Modes. Enable DMX-
512 checksums if you will be feeding DMX-512 from any
Gilderfluke & Company products (
usually enabled). The Re-
peater Control Channel and First Animation channel num-
ber were set on a previous tab.
8) MIDI Control Tab: Disable MIDI, unless you plan to use it.
Disable MIDI Notes Trigger Animation Playback, unless you
plan to use it. Set MIDI Channel Number and Animation First
Note number if you will be using MIDI, otherwise, ignore
them.
9) Flash Setup Tab: Enable Animation from Flash, unless you
will never be using the onboard show storage.
Enable/Disable outputs when stopped, as needed. Leave
the Write Protect Flash unchecked, or you will not be able to
save the show you are creating to the Mp3-50/8 or Mp3-
50/40. Disable it after you have completed programming, if
needed. The Repeater Control Channel and First Animation
channel number were set on a previous tab.
d) Mp3-50/40 with Two Audio Level Control Channels: This config-
uration adds two analog channels which can be used to inde-
pendently control the left and right audio levels of the Mp3 Play-
er as a part of the show control file.
This configuration gives you a show capacity of approximately
36 minutes in the onboard Flash memory.
Starting with a blank site file, you can create all the channels
you need by:
1) Open PC•MACs, Create a 'New' show. Go to 'Channels
Pulldown'/'Create Multiple Channels....'.
2) Select forty-eight digital and zero analog channels. The digi-
tals that come out of the J6 connector are addressed from
‘0’ through ‘3’. The digitals that will come out of the 1/4 J6
are addressed at ‘4’. The last eight outputs (on channel ‘5’)
will be used for triggering the Mp3 Player.
3) Click ‘OK’ to create these channels.
4) Go to PC•MACs 'Channels Pulldown'/'Create Multiple Chan-
