f) Mp3-50/40 with Sixteen DMX-512 Channels: This configuration
goes back to the typical installation (‘b’ above) and adds sixteen
channels of DMX-512 output. If you are using Serial RealTime Up-
date mode during programming, you will only be able to access
the DMX-512 channels through the serial port. The show control
ports are located above sixteen channels, so they will not be up-
dated in RealTime.
The DMX-512 transmission always starts with the first channel
stored in the Flash memory, and transmits the first sixteen consec-
utive channels. This is where the DMX-512 data will live.
This configuration consumes eighteen channels of Flash. This
gives a capacity of 13 minutes in the onboard Flash memory.
Starting with a blank site file, you can create all the channels
you need by:
1) Open PC•MACs, Create a 'New' show. Go to 'Channels
Pulldown'/'Create Multiple Channels....'.
2) Select forty-eight digital and sixteen analog channels. The
analogs are on channels ‘0’ through ‘15’. The digitals that
come out of the J6 connector are addressed from ‘16’
through ‘19’. The digitals that will come out of the 1/4 J6 are
addressed at ‘20’. The last eight outputs (on channel ‘21’)
will be used for triggering the Mp3 Player.
3) Click ‘OK’ to create these channels.
When you have finished programming your show you will
AutoDownload it to the Mp3-50/8. Set the ‘First Channel’ to ‘0’
and the ‘Last Channel’ to ‘21’ on the PC•MACs File Pulldown/Save
as AutoDownload.... window.
In the Mp3 Configurator Program:
1) Track Setup Tab: Point it at your SmartMedia card and set as
needed.
2) PlayLists Tab: Set up as needed, if needed.
3) Audio Tab: Set audio levels and EQ as needed. Disable Re-
alTime Audio Level Control. Enable/Disable amplifier as
needed.
4) Input Tab: You will be using the MPU inputs in this case. Dis-
able ALL of the Optoisolated Inputs.
5) MPU Input Tab: Set up the inputs to select and start Au-
