Logic Functions - Book 2
SUPERVISORY MESSAGE BLOCK
8-79
Table 8-8. Supervisory Message Block Attributes, Valid Values, Mnemonics, and Data Types
Field Name / Attribute Mnemonic Valid Values CWR Data Type Attr
Unacked Failure Diag FUNACK NO (0), YES (1) – WR Discrete 06
Unacked Failure Diag Quality FUNACKQ GOOD (0), BAD (1) – WR Discrete 07
Failure Counter FCNT – WR Count 08
Failure Counter Quality FCNTQ GOOD (0), BAD (1) – WR Discrete 09
Send Command SEND NO (0), YES (1) – WR Discrete 10
Active A NO (0), YES (1) – WR Discrete 11
Active Quality AQ GOOD (0), BAD (1) – WR Discrete 12
Fail FAIL NO (0), YES (1) – WR Discrete 13
Fail Quality FAILQ GOOD (0), BAD (1) – WR Discrete 14
Maximum time allowed for
message transaction RTIME NONE, msec-time CWR msec_time 15
Maximum number of retries
before failure RETRY 0 - 255 CWR Long State 16
Message Code CODE 0 No Value
1 Acknowledgment
2 Timeout
3 Not configuring source
4 Service manual
5 Main database invalid
6 Invalid block
7 Source not authorized
8 Previous Shutdown fault
11 Invalid attribute
12 Locked state
14 Invalid parameter
15 Attribute not writeable
17 Block not present
18 Invalid mode
19 Invalid write by
configuration
22 Instrument state in
transition
23 Invalid set-point state
24 Invalid remote/local
status
26 Invalid message
31 In HOLD state – WR Long State 17
Initial Data (Result) R local data CWR any 18
Result Quality RQ GOOD (0), BAD (1) – WR Discrete 19
Send Input SENDINP NONE, LSP C – R Discrete 20
Data Input DATAINP NONE, local value, LSP CWR any 21
