Logic Functions - Book 2
Totalizer Block
8-98
Table 8-9. Totalizer Block Attributes, Valid Values, Mnemonics, and Data Types (Cont’d)
Predetermined
Count 1 Status
Quality
PC1STATQ GOOD (0), BAD (1)
-WR Discrete
22
Pred. Count 2
Status
PC2STAT
FALSE (0), TRUE (1) Default value is FALSE. CWR Discrete
23
Predetermined
Count 2 Status
Quality
PC2STATQ GOOD (0), BAD (1)
-WR Discrete
24
Mode
MODE
RUN (0) or HOLD (1)
CWR Discrete
25
Mode Quality
MODEQ
GOOD (0), BAD (1)
-WR Discrete
26
Analog Input
ANALINP
The default local value is 0.0.
CWR Floating
Point
27
Direction Input
DIRINP
UP (1) or DOWN (0). The default local data
value is 1 (UP).
CWR Discrete
28
Reset Input
RESINP
NONE, local data or source pointer. The
default local data value is FALSE.
CWR Discrete
29
Stop Input
STOPINP
NONE, local data or source pointer. The
default local data value is FALSE.
CWR Discrete
30
Run Input
RUNINP
NONE, local data or source pointer. The
default local data value is FALSE.
CWR Discrete
31
Hold Input
HOLDINP
NONE, local data or source pointer. The
default local data value is FALSE.
CWR Discrete
32
Block Type
TOT
This is the Totalizer Block type. Block type code is 11.
00
Version (VERSION) ........................................................................................................... – – R
The TOT block is at version 1.
01
Block Length (BLKLEN) .................................................................................................... – – R
Number of data base bytes used by this block.
02
State (STATE) .................................................................................................................... CWR
All block state changes are reported as events. See IB-23G600 (I/O Logic Book 1) Section
2.4.1, State Changes for additional information. Controls algorithm execution.
RUN
0
Normal Operation. Block is executed.
HOLD
1
Block is not executed. Qualities retain previous values.
OFF
2
Block is not executed. Qualities will be BAD.
DEBUG
3
Block is not executed. No fields are updated. Most attributes are
writeable.
