Logic Functions - Book 2

SEQUENCE BLOCK

10-13

10.4.5 Attribute

Descriptions

The mnemonics, valid values, and data types for all fields that can be selected for display
and/or be used in making softwiring connections are listed in Table 10-1. A description of
each attribute is provided in the attribute list that follows the table.

The following conventions are used in presenting the attribute information in Table
10-1.

Configurable Attributes

Shown in bold text

Non-Configurable Attributes Shown in italicized text

CWR

Identifies if an attribute is Configurable, Writeable, and/or
Readable.

Table 10-1. Sequence Block Attributes, Valid Values, Mnemonics, and Data Types

Field Name /

Attribute

Mnemonic

Valid Values

CWR

Data Type

Attr

Version

VERSION

1

– – R Long State

00

Block Length

BLKLEN

– – R Count

01

Block State

STATE

RUN, HOLD, OFF, DEBUG

CWR Short State

02

Bad Inputs

BADINP

REJECTED(0), ACCEPTED(1)

CWR Discrete

03

Diagnostic Group

SUPPGRP

NONE, 1, 2, 3, 4, 5, 6, 7

CWR Long State

04

Bad Input Error

IERRS

ENABLE(0), SUPPRESS(1)

CWR Discrete

05

Input Error Unacknowledged

IERRU

NO(0), YES(1)

-WR

Discrete

06

Input Error Unacknowledged
Quality

IERRUQ

GOOD(0), BAD(1)

-WR

Discrete

07

Input Error Active

IERRA

NO(0), YES(1)

-WR

Discrete

08

Input Error Active Quality

IERRAQ

GOOD(0), BAD(1)

-WR

Discrete

09

Calculation Error

CERRS

ENABLE(0), SUPPRESS(1)

CWR Discrete

10

Calc. Error Unacknowledged

CERRU

NO(0), YES(1)

– WR Discrete

11

Calc. Error Unacked Quality

CERRUQ

GOOD(0), BAD(1)

– WR Discrete

12

Calc. Error Active

CERRA

NO(0), YES(1)

– WR Discrete

13

Calc. Error Active Quality

CERRAQ

GOOD(0), BAD(1)

– WR Discrete

14

Bad Step Error

INVSTS

ENABLE(0),SUPPRESS(1)

CWR Discrete

15

Bad Step Error
Unacknowledged

INVSTU

NO(0), YES(1)

-WR

Discrete

16

Bad Step Error
Unacknowledged Quality

INVSTUQ

GOOD(0), BAD(1)

-WR

Discrete

17

Bad Step Error Active

INVSTA

NO(0),YES(1)

-WR

Discrete

18

Bad Step Error Active Quality

INVSTAQ

GOOD(0),BAD(1)

-WR

Discrete

19

Failure Error

FAILS

ENABLE(0), SUPPRESS(1)

CWR Discrete

20

Failure Error Unacked

FAILU

NO(0), YES(1)

-WR

Discrete

21

Failure Error Unacked Quality

FAILUQ

GOOD()),BAD(1)

-WR

Discrete

22

Failure Error Active

FAILA

NO(0),YES(1)

-WR

Discrete

23

Failure Error Active Quality

FAILAQ

GOOD(0),BAD(1)

-WR

Discrete

24
