Logic Functions - Book 2

TABLE LIBRARY BLOCKS

SECTION 9

TABLE FUNCTIONS DATA BASE PARAMETERS

9.1

TABLE LIBRARY BLOCKS

Table function blocks cannot operate independently in the instrument database. These blocks
must be placed in a loop compound. Table blocks are selected from the Table library. The
piecewise table is the only resource available in this library group.

PW

Piecewise Table Block. This block is a data block that supports 60 pairs of
X,Y floating point coordinates for user defined linearizations or recipe data.
Linearization data is sent to the LN block using the TABLEOUT connection.
Recipe data is available on a per point basis.

The actual number of blocks in a database depends upon configuration memory and the mix
of block types.

NOTE

Normally, occurrence numbers are compiled in consecutive order (e.g., TM1,

then TM2, then TM3 etc.). Forcing higher occurrence numbers out of
order uses up memory space.
