Logic Functions - Book 2
CONFIGURING THE SEQUENCE BLOCK
11-9
Defining the I/O Modules
The I/O modules required for this application example are as follows:
•
Three digital input modules to accept the signals from the high level switch, low level
switch, and the feedback signal from the drain valve.
•
One RTD module to accept the product temperature signal (an RTD input function block
is required to condition the signal from the RTD module).
•
Two digital output modules to generate the open and close signals for the fill valve and
drain valve.
See IB-23G600 for more information about I/O modules. Define the I/O modules using the
step-by-step instructions in Table 11-7.
Table 11-7. I/O Module Definition Procedure
Step
Procedure
Comments
1
From the Algorithm window, select the following icons
and place them in the workspace:
3 DIM (Digital Input Modules)
1 WRIM (3-Wire RTD Module)
2 DOM (Digital Output Modules)
2
Double click to query the first DIM. The Digital Input
Module Block properties appear.
3
Select the Name field and type the name LSL-1M. Also
enter the proper slot number for the module.
The default values for all other block
attributes are acceptable without
change. Note that it is not necessary
to specify a number in the Slots field.
The slot location can also be defined
using the I/O Graphic display.
4
Select OK.
Note that the assigned tag name now
appears in the DIM block.
5
Using the procedure of Steps 2 through 4, assign
names to each remaining I/O module as follows:
Second DIM:
LSH-1M
Third DIM
DrainingM
WRIM
TE
First DOM
Fill
Second DOM
Drain
6
From the Algorithm window, select the following icons
and place them in the workspace. Assign names to
each block as follows
First DI (Digital Input Block)
LSL-1
Second DI (Digital Input Block)
LSH-1
Third DI (Digital Input Block)
Draining
1 RTI (RTD Input Block)
TI
9
Select the RTI block Temperature Scale Field and
select Fahrenheit.
Default entries for all other attributes
are acceptable without change.
10
Select enter to return to the workspace display.
