Totalizer Block
8-97
8.10.3 Totalizer Block Parameters
The mnemonics, valid values, and data types for all fields that may be selected for display
and/or be used in making softwiring connections are listed in Table 8-9. A description of each
attribute is provided in the attribute list that follows the table. Initial values are written when
the block is initially downloaded. They may be overwritten when the block executes.
Table 8-9. Totalizer Block Attributes, Valid Values, Mnemonics, and Data Types
Field Name /
Attribute
Mnemonic Valid Values CWR Data Type Attr
Version VERSION Version number of the block. --R Long State 00
Block Length BLKLEN Number of database bytes in the block. --R Count 01
State STATE RUN (0), HOLD (1), OFF (2), DEBUG (3). CWR Short State 02
Bad Inputs BADINP REJECTED (0), ACCEPTED (1). CWR Discrete 03
Input Type INTYPE ANALOG TYPE (0)
PULSE TYPE (1) (Not Available) C-R Discrete 04
Auto Wrap WRAP NO (0), YES (1) Default is 0 (NO). CWR Discrete 05
Rate RATE Analog Type only. Totalizer rate can be per:
SECONDS (0), MINUTES (1), HOURS (2),
DAYS (3). Default is 0 (SECONDS). CWR Short State 06
Restart Mode RESMODE Cold or frozen restart initialization value.
RUN (0), HOLD (1), PREV (2)
Default value is PREV.
CWR Short State 07
Command CMD The value read from this location will always
be 0. Commands are:
RESET (1), STOP(2), RUN (3), HOLD (4) -WR Long State 08
Threshold THRESH Allowed value is 0.0 or greater. Default is 0.0. CWR Floating
Point
09
Scale Factor SF A number greater than zero (0) where 10.0
divides total by 10 and 0.1 multiplies total by
10. Default is 1.0. CWR Floating
Point
10
High Limit HL This value must be greater than the low limit
and less than or equal to 9999999.0. Default
is 9999999.0. CWR Floating
Point
11
Low Limit LL This value must be less than the high limit and
equal or greater than 0.0. Default is 0.0. CWR Floating
Point
12
(Predetermined)
Pred. Count 1 PC1 Valid value is 0.0 to 9999999.0. Default is 0.0. CWR Floating
Point
13
(Predetermined)
Pred. Count 2 PC2 Valid value is 0.0 to 9999999.0. Default is 0.0. CWR Floating
Point
14
Total Count TC 0.0 to 9999999.0. The default value is 0.0. CWR Floating
Point
15
Total Count Quality TCQ GOOD (0), BAD (1) -WR Discrete 16
High Limit Status HLSTAT FALSE (0), TRUE (1) Default value is FALSE. CWR Discrete 17
High Limit Status
Quality HLSTATQ GOOD (0), BAD (1) -WR Discrete 18
Low Limit Status LLSTAT FALSE (0), TRUE (1) Default value is FALSE. CWR Discrete 19
Low Limit Status
Quality LLSTATQ GOOD (0), BAD (1) -WR Discrete 20
Pred. Count 1
Status PC1STAT FALSE (0), TRUE (1) Default value is FALSE. CWR Discrete 21
