Logic Functions - Book 2
SEQUENCE BLOCK
10-25
501
Output 1 (OUT 1)................................................................................................................. -WR
503
505
through
559
Output 64 (OUT64).............................................................................................................. -WR
Each block output is the data value specified by the output definition as configured for the
current operating step in a sequence. Writeable only in DEBUG. See 10.4.3 Output
Definitions and 10.4.4 Step Definitions for additional information.
502
Output 1 Quality (OUT1Q).................................................................................................. -WR
504
506
through
560
Output 64 Quality (OUT64Q).............................................................................................. -WR
The output quality depends on any block input and its quality. If Pass Through Quality
(Attribute No.44) is set YES, the quality of all inputs which are designated as outputs is
passed through the block without a check.
GOOD
0
Quality when the block STATE is RUN and Attribute No. 44 is set
YES.
BAD
1
Quality when the block STATE is HOLD, OFF, or RUN with bad input
quality and Attribute No. 44 set NO.
10.5 BLOCK
EVENTS
The sequence block event codes and their suggested run time display messages are given
below. See the referenced data base attributes (in brackets) for additional information. See
System Event Block, Logic Functions - Book 1, IB-23G600 for a description of event
transactions.
0
BLOCK STATE SET TO RUN
1
BLOCK STATE SET TO HOLD
2
BLOCK STATE SET TO OFF
3
BLOCK STATE SET TO DEBUG
4
SEQ BLOCK BAD INPUT DETECTED (Attribute No. 05)
5
SEQ BLOCK CALC ERROR (Attribute No.10)
6
SEQ BLOCK STEP OUT OF RANGE (Attribute No. 15)
7
SEQ BLOCK FAILURE (Attribute No. 20)
8
BLOCK SET TO MANUAL
9
BLOCK MODE SET TO AUTO
10
BLOCK MODE SET TO SEMI-AUTO
