background image

Logic Functions - Book 2

PIECEWISE TABLE BLOCK

9-7

9.2.2

Piecewise Table Block Parameters

The mnemonics, valid values, and data types for all fields that may be selected for display
and/or be used in making softwiring connections are listed in Table 9-1. The following further
defines the piecewise table block configuration parameters.

Block Type
PW

This is the piecewise table block type. The block type code is 13.

Occurrence
1 to 4096

There may be up to 4096 ‘instances’ allowed of the PW block type.

Editing Activity
INSERT or DELETE can be selected to insert or delete an X,Y entry in the table.
The delete or insert line position is made through a prompt in the configurator.

Table 9-1. Piecewise Table Block Attributes, Valid Values, Mnemonics, and Data Types

Field Name /

Attribute

Mnemonic

Valid Values

CWR Data Type

Attr

Version

VERSION

1, 2

– – R Long State

00

Block Length

BLKLEN

Number of database bytes in
the block

– – R Count

01

Block State

STATE

RUN (0)

– – R Short State

02

Bad Inputs

BADINP

Accepted (1)

– – R Discrete

03

Can Be PW

CANBEPW NO (0), YES (1)

C – R Discrete

04

Can Be IPW

CANBEIPW NO (0), YES (1)

C – R Discrete

05

Number of Points

NUMPTS

0 to 60

C – R Count

06

X1 Value

X1

CWR Floating Pt

101

...

...

...

...

...

X60 Value

X60

CWR Floating Pt

160

Y1 Value

Y1

CWR Floating Pt

201

...

...

...

...

...

Y60 Value

Y60

CWR Floating Pt

260

00

Version (VERSION)............................................................................................................– – R
This block is at Version 2. Version 1 does not support attributes 4 through 260.

01

Block Length (BLKLEN).....................................................................................................– – R
Number of data base bytes used by this block.

02

State (STATE).....................................................................................................................– – R
This block is always RUN (block is executed). See IB-23G600 (Logic Book 1) Section 2.4.1,
State Changes
for additional information on block states.

03

Bad Inputs Accepted (BADINP) ........................................................................................– – R
Piecewise block processes data without a check on input quality and output quality is set to
good. See IB-23G600 (Logic Book 1) Section 2.3.2, Data Quality for additional information.

04

Can Be Piecewise (CANBEPW) ....................................................................................... C – R
If the X values are in ascending order and there are no duplicates, the table is marked as
usable for piecewise linearization.
