Logic Functions - Book 2
CONFIGURING THE SEQUENCE BLOCK
11-11
Compiling and Downloading the Project
The final phase of the configuration procedure is to compile the configured database. The
compilation function puts the configuration data into a file that can be downloaded to an
instrument. Initiate the compilation operation using the instructions in Table 11-9.
Table 11-9. Database Compilation Procedure
Step Procedure Comments
1 Save the database before compiling or downloading.
2 From the SEQLAB document, select the Instrument
menu Compile item.
3 Select OK. Do not reassign block occurrence numbers.
4 Do not select any of the Interface File Options; Select
OK and wait for completion of the operation. Upon
completion of the compilation, one of the following
messages appears:
Compile completed without error
There were compile errors
When the Compile Complete
message is obtained the
configuration is finished and a valid
strategy is obtained. In a real
application the strategy can be
downloaded to the Modcell
instrument at this point (Step 7).
5 If a compile error message is displayed, select the OK
box. A listing of the compile errors appears.
6 Examine the error listing, take appropriate corrective
action, then repeat Steps 1 through 4 until the
compilation is successful
7 From the SEQLAB document, select the Instrument
menu Download item. To perform other tasks related to
OPC client server activities, building
a tag list and using debug, see the
help files or refer to the ViZapp
tutorial.
